Dual Band 5GHz + 2.4 GHz Omni-Directional 802.11ac 12 dBi Gain Outdoor Antenna
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| SKU | ANT-OMNI-5812 |
| Connector | N-Female |
| Directivity | Omni-Directional |
| Supported Wireless Protocols | Wi-Fi 802.11ac |
| Gain | 12dBi |
| MPN | ANT-OMNI-5812 |
| Item Height | 25.6in. |
| Color | Gray |
| Brand | Premiertek |
| Connectivity | Wireless-Wi-Fi 802.11a |
| Frequency Bands | 2.4 GHz |
| Features | Dual-Band |
| Type | Antenna |
| Model | HornetTek |
This is a heavy duty high gain outdoor fiberglass antenna for the 2.4 & 5 Ghz WiFi frequencies.Has N-FEMALE connector, so designed to be use with N-MALE coaxial connector or device connector Pair with ALFA AWUS036ACH or AWUS036ACHM or other WiFi receivers with an external antenna connector + coaxial cable to provide outdoor extension for a dual band WiFi radio. This is NOT for Helium 915 MHz or LoRa IoT products. This is NOT a WiFi receiver and cannot pick up WiFi networks on its own. It must be paired with a WiFi radio and optionally coaxial cable to extend it from your WiFi radio. Frequency range（MHz） 2400-2483 5725-5850 Bandwidth（MHz） Gain（dBi） 8 dBi for 2.4 GHz 12 dBi for 5 GHz Half-power beam width（°） H:360 V:11 for 2.4 GHz H:360 V:8 for 5 GHz VSWR ≤1.5 for 2.4 GHz ≤2.0 for 5 GHz Input Impedance（Ω） 50 Polarization Vertical, Linear Maximum input power（W） 100 Lightning protection DC Ground Input connector type N Female Dimensions (mm) Φ25*950 Antenna weight（kg） 0.59 Operating temperature（°c） -40～60 Rated Wind Velocity（m/s） 60 Radome color WhiteWaterproof Standard IP65/ IP67 Mounting way Wall/ Pole-holding Mounting hardware（mm） ￠35-￠5
